Brand:AUK
Model: 5565113
Type:Li Polymer Battery
Capacity:5000mAh
Dimensions(L*W*H):113mm *65mm *5.5mm
Nominal voltage:3.7V;
Standard charge and discharge at 1C
OEM/ODM service offered
Feature:
3.7v lithium battery pack for psp battery
Charge current: standard 0.2 C5A and maximum 1C5A
Charge cut-off voltage: 4.20 0.03V
Standard discharge current: 0.2C5A
Maximum discharge current: 2.0C5A
Discharge cut-off voltage: 2.75V
Working Temperature:-20°~50°
Product with PCB protection features:
1. Over charge Protection
2. Over discharge protection
3. Overcurrent protection
4. Short protection
Application:
Widely used Original ForNotebook E-book tablet pc laptop power bank video game GPS AA-PLAN6AR Intelligent lockMobile phone Built-in battery MP4, MP5, GPS, power bank, remote controller, mobile phone, E-book, iPad, tablet, laptop, portable printer, fingerprint machine, POS machine, PSP, PC, Bluetooth speaker, digital camera, radio, portable DVD, MID, PAD, PDA, solar lamp, electric toys or other compatible devices powered by batteries with the same size and capacity.
Features
High quality and durable, less worry about battery's going dead within a short time.
Provides excellent continuous power sources to your device, features high energy density and extra long lifespan.
Portable emergence backup power, ideal batteries for DIY lovers !
Instructions
1. Please allow tiny size deviations due to human measurement.Please take a look at the size of the battery when you submit your order
2. When the battery is not in use, it should be removed from the device.
3. The “+” on the battery is the positive pole, The “-” on the battery is the positive pole that's the negative pole
4.
Again,look at the positive and negative ends of the battery and when you use it
Other Similar Ultra Thin Lipo Battery Model List
| Type | Model | Capacity
(mAh) | Voltage (V) | Thickness
(mm) | Width
(mm) | Length
(mm) | Weight
(g) |
| 1215 | 301215 | 25 | 3.7 | ≤3.0 | ≤12.5 | ≤15.5 | 1.0 |
| 401215 | 35 | 3.7 | ≤4.0 | ≤12.5 | ≤15.5 | 2.0 |
| 501215 | 45 | 3.7 | ≤5.0 | ≤12.5 | ≤15.5 | 2.0 |
| 1220 | 301220 | 40 | 3.7 | ≤3.0 | ≤12.5 | ≤20.5 | 2.0 |
| 401220 | 60 | 3.7 | ≤4.0 | ≤12.5 | ≤20.5 | 2.5 |
| 451220 | 70 | 3.7 | ≤4.5 | ≤12.5 | ≤20.5 | 2.5 |
| 501220 | 80 | 3.7 | ≤5.0 | ≤12.5 | ≤20.5 | 3.0 |
| 601220 | 100 | 3.7 | ≤6.0 | ≤12.5 | ≤20.5 | 3.0 |
| 1225 | 401225 | 90 | 3.7 | ≤4.0 | ≤12.5 | ≤25.5 | 3.0 |
| 501225 | 120 | 3.7 | ≤5.0 | ≤12.5 | ≤25.5 | 3.5 |
| 601225 | 150 | 3.7 | ≤6.0 | ≤12.5 | ≤25.5 | 4.0 |
| 1230 | 401230 | 110 | 3.7 | ≤4.0 | ≤12.5 | ≤30.5 | 3.0 |
| 501230 | 130 | 3.7 | ≤5.0 | ≤12.5 | ≤30.5 | 4.0 |
| 601230 | 160 | 3.7 | ≤6.0 | ≤12.5 | ≤30.5 | 5.0 |
| 1235 | 301235 | 90 | 3.7 | ≤3.0 | ≤12.5 | ≤35.5 | 3.0 |
| 401235 | 120 | 3.7 | ≤4.0 | ≤12.5 | ≤35.5 | 3.5 |
| 501235 | 160 | 3.7 | ≤5.0 | ≤12.5 | ≤35.5 | 4.0 |
| 601235 | 200 | 3.7 | ≤6.0 | ≤12.5 | ≤35.5 | 6.0 |
| 1245 | 401245 | 160 | 3.7 | ≤4.0 | ≤12.5 | ≤45.5 | 4.0 |
| 501245 | 200 | 3.7 | ≤5.0 | ≤12.5 | ≤45.5 | 6.0 |
| 601245 | 240 | 3.7 | ≤6.0 | ≤12.5 | ≤45.5 | 6.5 |
| 701245 | 280 | 3.7 | ≤7.0 | ≤12.5 | ≤45.5 | 7.0 |
| 1430 | 401430 | 130 | 3.7 | ≤4.0 | ≤14.5 | ≤30.5 | 3.5 |
| 451430 | 150 | 3.7 | ≤4.5 | ≤14.5 | ≤30.5 | 4.0 |
| 551430 | 180 | 3.7 | ≤5.5 | ≤14.5 | ≤30.5 | 5.0 |
| 651430 | 210 | 3.7 | ≤6.5 | ≤14.5 | ≤30.5 | 6.0 |
| 1435 | 501435 | 200 | 3.7 | ≤5.0 | ≤14.5 | ≤35.5 | 6.0 |
| 601435 | 250 | 3.7 | ≤6.0 | ≤14.5 | ≤35.5 | 6.5 |
| 701435 | 300 | 3.7 | ≤7.0 | ≤14.5 | ≤35.5 | 7.0 |
| 1530 | 501530 | 180 | 3.7 | ≤5.0 | ≤15.5 | ≤30.5 | 5.0 |
| 601530 | 220 | 3.7 | ≤6.0 | ≤15.5 | ≤30.5 | 6.0 |
| 701530 | 250 | 3.7 | ≤7.0 | ≤15.5 | ≤30.5 | 6.5 |
